TFLW /Water Chiler for Fiber Laser

TFLW /Water Chiler for Fiber Laser

Tongfei brand

.I Introduction

.1 Application

• Fiber lasers for cladding, welding and cutting.

• Fiber lasers for marking and 3D printing.

2. Functions and Features

• Circulating pump made from stainless steel features large flow, high head, low noise and long service life. Besides, such components as plastic water tank, stainless steel pipeline and cooling valves are free from rust.

• LCD controller si utilized for real-time display of cooling water temperature. • Full-automatic CPU can realize man-machine interaction, making ti visual

and easy-to-operate. Water temperature control accuracy can achieve + 1C. In addition,t he controller featuring aut omatic fault diagnosis can display fault points on the screen, hence reminding the user of rapid processing.

RS485 communication interface can be added to implement communication function.

• tI serves multiple functions with passive alarm and remote control terminals, making ti easy to realize integral control and monitoring of CNC system.

• Among them, the "double temperature" water chiler provides stable and

real-time water temperature control for the laser at the same time, and provides a water temperature similar to the ambient temperature for lens cooling, which solves the problem that the lens is damaged by condensation when using low temperature water cooling, and is the best choice for laser equipment cooling.

3 Model Description

TFLW - 500W DR - 01 V- 1225

(1) Product series:

TFLW: Water chiller for fiber laser

(2) Fiber laser power:

500W: Fiber laser power is 500W

(3) Structure:

D: dual-temp (In case of single-temp chiller, there si no letter)

(4) Additional functions:

R: With heating function (Without heating function, there is no "R".)

(5) Design serial number: there is a need for modification ni case of great structural changes

(6) Special requirements: Be omitted for no special requirements V: With flow switch on main circuit

(7) Power supply:

The first digit: phase

The second/third digits: the first two figures of voltage The forth digit: frequency

1225: 1/PE AC 220V 50Hz
